FLK-TIX580 9HZ Thermal Imager; 640x480; 9 HZ, SR
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
24 135,44 €
EAN: 0095969835169
MPN: 4841945
Package: 1
Estimate delivery time at our warehouse (approx.):
2-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | FLK-TIX580 9HZ Thermal Imager; 640x480; 9 HZ, SR |
| Brand | Fluke |
| Categories |
Electrical Test Equipment
|
| Country of origin | US |
| Harmonized System Code | 9025 1900 00 |
| Display diagonal | 5.7 inch |
| Degree of protection (IP) | IP54 |
| Temperature measuring range | -20-850 °C |
| Max. battery duration | 3 h |
| Thermal image | Yes |
| Thermal sensitivity at 30 °C | 0.05 °C |
| Video recording | Yes |
| Thermal-/visual image (in one image) | Yes |
| Sensor resolution (horizontal) | 640 px |
| Sensor resolution (vertical) | 480 px |
| Display resolution (horizontal) | 640 px |
| Display resolution (vertical) | 480 px |
Packing details
| Packing level 1 | 0095969835169 |
Other Technical data
| Weight | 1.54 kg |
| With memory function | Yes |
| Power consumption | 7.5 W |
| Digital zoom | 8 |
| USB connection | Yes |
| Auto focus | Yes |
| Ambient temperature | -10-50 °C |
| With touch screen | Yes |
| External power supply required | No |
| Ethernet | No |
| Gigabit Ethernet | No |
| Relative accuracy of measurement | 2 % |
| Bluetooth interface | Yes |
| Wi-Fi-compatible | Yes |
| Internal memory | Yes |
| With stand holder | No |
| Input voltage at AC 50 Hz | 110-230 V |
| Input voltage at AC 60 Hz | 110-230 V |
| Input voltage at DC | 7.2-15 V |
| With communication interface RS-232 | No |
| With communication interface RS-485 | No |
| HDMI-connection | Yes |
| With laser | Yes |
| SD-card slot | No |
| MicroSD-card slot | Yes |
| Battery powered | Yes |
| Auto orientation | No |
| Visual image | Yes |
| Wave band | 7.5-14 µm |
| Detector cooled | No |
| Field of view (FOV) vertical | 24 ° |
| Field of view (FOV) horizontal | 34 ° |
| Instantaneous field of view (IFOV) | 0.93 m rad |
| With built-in torch | Yes |
| Analogue video out | No |
| FireWire (IEEE1394) connection | No |
| Focus stacking | Yes |
| Image averaging | Yes |
| With laser distance measurement | Yes |
| Frames per second (fps) | 9 |
| Increase image size | Yes |
| With digital alarm | No |
| Suitable for exchangeable lenses | Yes |
| CompactFlash I card slot | No |
| CompactFlash II card slot | No |
| MiniSD-card slot | No |
| With humidity sensor | No |
Downloads
Description
Rugged, superbly engineered 640 x 480 thermal imaging camera, provides large 5.7-inch responsive LCD touchscreen with 150% more viewing area than 3.5-inch screen, features 240° rotating screen for unmatched shooting flexibility, provides 4x the pixel data with on-camera SuperResolution to create a 1280 x 960 resolution image.
