THERM-MAGN 4-6,3A+ GVAN11

Name: THERM-MAGN 4-6,3A+ GVAN11
Brand: Schneider Electric
Availability: PreOrder

Order only Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	THERM-MAGN 4-6,3A+ GVAN11
Brand	Schneider Electric
Country of origin*	FR
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8536 2010 00
ETIM	EC000074
Rated permanent current Iu	6.3 A
Number of poles	3
Rated operating voltage	0-690 V
Overload release current setting	4-6.3 A
Degree of protection (IP)	IP20
Rated short-circuit breaking capacity lcu at 400 V, AC	100 kA
Adjustment range undelayed short-circuit release	78 A

Packing level 1

3389110823295

Width	54 mm
Height	89 mm
Depth	78.2 mm
Rated operation power at AC-3, 400 V	2.2 kW
With integrated auxiliary switch	Yes
With integrated under voltage release	No
With thermal protection	Yes
Type of electrical connection of main circuit	Screw connection
Type of control element	Push button
Switch off technique	Thermomagnetic
Rated operation power at AC-3, 230 V	1.5 kW
Phase failure sensitive	Yes
Device construction	Complete device in housing
