THERM-MAGN 2,5-4A+ GVAE11
Order only
Price (excl. VAT):
38,00 €
EAN: 3389110823189
MPN: GV2ME08AE11TQ
Box: 24
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | THERM-MAGN 2,5-4A+ GVAE11 |
| Brand | Schneider Electric |
| Categories |
Motor protection circuit-breakers
|
| Country of origin | FR |
| Harmonized System Code | 8536 2010 00 |
| Rated permanent current Iu | 4 A |
| Number of poles | 3 |
| Rated operating voltage | 0-690 V |
| Overload release current setting | 2.5-4 A |
| Degree of protection (IP) | IP20 |
| Rated short-circuit breaking capacity lcu at 400 V, AC | 100 kA |
| Adjustment range undelayed short-circuit release | 51 A |
Packing details
| Packing level 1 | 3389110823189 |
Other Technical data
| Width | 45 mm |
| Height | 89 mm |
| Depth | 78.2 mm |
| Rated operation power at AC-3, 400 V | 1.5 kW |
| With integrated auxiliary switch | Yes |
| With integrated under voltage release | No |
| With thermal protection | Yes |
| Type of electrical connection of main circuit | Screw connection |
| Type of control element | Push button |
| Switch off technique | Thermomagnetic |
| Rated operation power at AC-3, 230 V | 0.75 kW |
| Phase failure sensitive | Yes |
| Device construction | Complete device in housing |
