Terminal block 70 mm² phase, 1000V/192A, screw

Order only

EAN: 3250610133507

MPN: KR700L

Package: 1

Price (excl. VAT)

27,94 €

per unit

MOQ: 1

EDT to our warehouse: 4-6 weeks

This price is valid until next price list or while stock lasts

Technical Information

Item condition	New
Manufacture name	Terminal block 70 mm² phase, 1000V/192A, screw
Brand	Hager
Categories	DIN Rail Terminal Blocks
Country of origin*	DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8536 9010 00
ETIM	EC000897
Mounting method	DIN rail (top hat rail)/G-rail TH35/G32
Rated voltage	1000 V
Type of electrical connection 1	Screw connection
Type of electrical connection 2	Screw connection
Number of levels	1
Number of clamp positions per level	2
Connectable conductor cross section solid-core	16 mm²
Connectable conductor cross section fine-strand with cable end sleeve	16-70 mm²
Connectable conductor cross section fine-strand without cable end sleeve	16-70 mm²
Connectable conductor cross section multi-wired	16-95 mm²
Rated current In	192 A

Packing level 1

3250610133507, 3250610133507

Colour	Beige
Width	20.5 mm
Height	75 mm
Depth	85 mm
Operating temperature	-60-130 °C
Closing plate required	No
Internally connected stages	No
Material insulation body	Thermoplastic
Explosion-tested version 'Ex e'	Yes
