Terminal block 35 mm² neutral, 500V/125A, screw

Order only

EAN: 3250610133576

MPN: KR350N

Package: 1

Price (excl. VAT)

8,04 €

per unit

MOQ: 1

EDT to our warehouse: 4-6 weeks

This price is valid until next price list or while stock lasts

Technical Information

Item condition	New
Manufacture name	Terminal block 35 mm² neutral, 500V/125A, screw
Brand	Hager
Categories	DIN Rail Terminal Blocks
Country of origin*	RO
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8536 9010 00
ETIM	EC000897
Mounting method	DIN rail (top hat rail)/G-rail TH35/G32
Rated voltage	500 V
Type of electrical connection 1	Screw connection
Type of electrical connection 2	Screw connection
Number of levels	1
Number of clamp positions per level	2
Connectable conductor cross section solid-core	2.5-16 mm²
Connectable conductor cross section fine-strand with cable end sleeve	2.5-35 mm²
Connectable conductor cross section fine-strand without cable end sleeve	2.5-35 mm²
Connectable conductor cross section multi-wired	2.5-50 mm²
Rated current In	125 A

Packing level 1

3250610133576, 3250610133576

Colour	Blue
Width	16 mm
Height	60 mm
Depth	62.5 mm
Operating temperature	-60-130 °C
Closing plate required	No
Internally connected stages	No
Material insulation body	Thermoplastic
Explosion-tested version 'Ex e'	No
