Terminal block 16 mm² neutral, 800V/76A, screw
Order only
EAN: 3250610133552
MPN: KR160N
Package: 1
Price (excl. VAT)
2,94 €
per unit
MOQ: 1
EDT to our warehouse: 4-6 weeks
Price valid until 01.01.99 or while in stock
Technical Information
| Item condition | New |
| Manufacture name | Terminal block 16 mm² neutral, 800V/76A, screw |
| Brand | Hager |
| Categories |
DIN Rail Terminal Blocks
|
| Country of origin* | CZ |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8536 9010 00 |
| ETIM | EC000897 |
| Mounting method | DIN rail (top hat rail)/G-rail TH35/G32 |
| Rated voltage | 690 V |
| Type of electrical connection 1 | Screw connection |
| Type of electrical connection 2 | Screw connection |
| Number of levels | 1 |
| Number of clamp positions per level | 2 |
| Connectable conductor cross section solid-core | 1.5-16 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve | 1.5-16 mm² |
| Connectable conductor cross section fine-strand without cable end sleeve | 1.5-16 mm² |
| Connectable conductor cross section multi-wired | 1.5-25 mm² |
| Rated current In | 76 A |
Packing details
| Packing level 1 | 3250610133552, 3250610133552 |
Other Technical data
| Colour | Blue |
| Width | 12 mm |
| Height | 60 mm |
| Depth | 46.5 mm |
| Operating temperature | -50-120 °C |
| Closing plate required | Yes |
| Internally connected stages | No |
| Material insulation body | Thermoplastic |
| Explosion-tested version 'Ex e' | No |
Downloads
Product data sheet
Deep link REACH
Declaration RoHS
Declaration DOC CE (Declaration of conformity CE)
Description
Rijgklem 16 mm² nul, 800V/76A, schroef
