D-LAN-19"-8 - Surge protection device

In stock: No Vendor stock: No Minimal order quantity: 1

Price (excl. VAT):

898,73 € per pcs

This price is valid until 24.12.25

EAN: 4017918962814

MPN: 2880163

Box: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	D-LAN-19"-8 - Surge protection device
Brand	Phoenix Contact
Categories	Surge Protection Devices (SPD)
Country of origin	DE
Harmonized System Code	8536 3010 00
Max. continuous voltage AC	0 V
Nominal discharge surge current (8/20)	0.35 kA
Nominal load current	1.5 A
Voltage protection level core/core	50 V
Max. continuous voltage DC	6 V
Voltage protection level core/signal ground	0 V

Packing details

Packing level 1

4017918962814, 4017918962814

Other Technical data

Connection 1	RJ45
Lightning impulse current (10/350 µs)	0 kA
With remote signalling contact	No
Number of conductors (without earthing)	0
Limiting frequency	0 MHz
Explosion-tested version	No
Voltage protection level core/earth	40 V
Signalling at the device	None
Voltage protection level signal ground/protective ground	0 V
Assembly width	0 mm

Description

19" rack with 8 surge protected ports for data interfaces in Ethernet (1000Base-T), Token Ring and FDDI/CDDI networks in acc. with Class D/EN 50173 (CAT5e), connection on the protective device: RJ45 sockets
