SPOT VARIO 170 35 W 3000 K 24DEG WT
Order Only
Minimal order quantity: 1
Price (excl. VAT):
62,83 €
Split box: 10,00 €
EAN: 4058075104020
MPN: 4058075104020
Package: 1
Box: 4
Estimate delivery time at our warehouse (approx.):
1-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | SPOT VARIO 170 35 W 3000 K 24DEG WT |
| Brand | LEDVANCE |
| Categories |
Recessed lights
LEDVANCE SALE |
| Country of origin | CN |
| Harmonized System Code | 9405 1190 00 |
| Width | 170 mm |
| Colour rendering index CRI | 80-89 |
| Length | 170 mm |
| Height/depth | 129 mm |
| Lamp type | LED not exchangeable |
| Impact strength | IK03 |
| Nominal voltage | 220-240 V |
| Degree of protection (IP) | IP20 |
| Beam angle | Medium beam 21-40° |
| Colour temperature | 3000 K |
| Max. system power | 35 W |
| Rated luminous flux according to IEC 62722-2-1 | 3350 lm |
| Luminaire efficacy | 95 lm/W |
Packing details
| Packing level 1 | 4058075104020 |
| Packing level 2 | 4058075104037 |
| Packing level 3 | 4058075104020 |
Other Technical data
| Protection class | II |
| Outer diameter | 180 mm |
| Reflector | High-gloss |
| Lamp holder | None |
| Connection type | Other |
| Colour housing | White |
| Surface protection | Powder coating |
| Voltage type | AC |
| With movement sensor | No |
| Suitable for lamp power | 35 W |
| Type of control gear | LED operating device current-controlled |
| Suitable for wall mounting | No |
| Energy efficiency class | A++ |
| With light sensor | No |
| Suitable for suspended mounting | No |
| Number of poles | 2 |
| Housing material | Aluminium |
| Light outlet | Direct |
| Light sharing | Symmetric |
| Material cover | Plastic, structured |
| Emergency power supply integrated | No |
| With light source | Yes |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | No |
| Covering of the luminaire with thermally insulating material possible | No |
| Suitable for number of lamps | 0 |
| Suitable for built-in mounting | Yes |
| With control gear | Yes |
| Suitable for workplace according to EN 12464-1 | No |
| Suitable for surface mounting | Yes |
| Surface brushed | No |
| Colour of light | White |
| Adjustability | Rotating and swivelling |
| Suitable for traverse mounting | No |
| Suitable for pedestal/floor mounting | No |
| Suitable for light-track mounting | No |
| Suitable for clamp-mounting | No |
| Constant light output (CLO) | No |
| IFTTT support available | No |
| Luminous flux | 3350 lm |
| Type of wiring | Ending |
| Rated life time L70/B50 at 25 °C | 50000 h |
| Rated life time L80/B10 at 25 °C | 45000 h |
| Colour consistency (McAdam ellipse) | SDCM5 |
| Total harmonic distortion | 19 |
| Photobiological safety according to EN 62471 | RG1 |
| Rated ambient temperature according to IEC62722-2-1 | -20-45 °C |
| Filament test according to IEC 60695-2-11 | 650 °C - 30 s |
| LED nominal current at constant current | 850 mA |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming GPRS | No |
| Dimming LineSwitch | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off | No |
| Dimming phase cut-on | No |
| Dimming programmable | No |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| No dim function | Yes |
| Light distributor | Reflector |
| Dimming depending on control gear | No |
| Suitable for low voltage cable system | No |
| Dimming DSI | No |
| Energy efficiency class of the built-in lamp | A++, A+, A (LED) |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Dimming DALI-2 | No |
| Colour temperature adjustable | No |
| Luminous flux adjustable | No |
| Beam angle adjustable | Positions |
| Exchangeable control gear | Yes |
| Built-in diameter | 170 mm |
| Suitable for ceiling mounting | Yes |
| Built-in height/depth | 150 mm |
| Power factor | 0.9 |
Downloads
Product picture
Others
Product data sheet
Instructions for use
Declaration DOC CE (Declaration of conformity CE)
Description
This device is an LED driver designed to supply constant current for LEDs in lighting systems. It regulates and converts the input electrical power to ensure safe, stable operation of connected LED modules while optimizing energy efficiency.
**Electrical Specifications**
Input voltage range: 220–240 V AC — compatible with standard mains power in most regions. Frequency: 50/60 Hz. Power factor compliance ensures reduced harmonic distortion at typical loads.
**Physical Characteristics**
Compact housing suitable for integration into small spaces or enclosed fixtures. Screw terminals facilitate secure wiring connections during installation—reliable anchoring even under minor vibration conditions.
**Performance Parameters**
Output current configuration: 250 mA (constant). Maximum output power rating of 10 W—applies within specified thresholds only. Designed for non-dimmable applications; dimming unsupported due to internal circuitry constraints.
- Operates within a temperature range of -20°C to +50°C without external cooling mechanisms required.
- Not waterproof or resistant to prolonged exposure to moisture.
- Safety standards certification includes ENEC and CE approvals.
- Overload protection features minimize damage risks during electrical surges.
- Intended solely for indoor use in dry environments.
- Compatible with DC-compatible LED modules; check product datasheets before pairing usage cases fully clarified.
