SPD 3P pluggable 75kA ind.+cont. TNC
Discontinued
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | SPD 3P pluggable 75kA ind.+cont. TNC |
| Brand | Hager |
| Harmonized System Code | 8535 4000 00 |
| ETIM | EC000381 |
| Mounting method | DIN rail (top hat rail) 15 mm |
| Voltage protection level | 1.5 kV |
| Follow current extinguishing capability | 50 kA |
| Max. continuous voltage AC | 255 V |
| Nominal voltage AC | 400 V |
| Category type 1 | Yes |
| Voltage protection level L-N | 1.5 kV |
| Max. continuous voltage DC | 0 V |
| Degree of protection (IP) | IP20 |
Packing details
| Packing level 1 | 3250615660916, 3250615660916 |
| Packing level 2 | 3250615660916 |
| Packing level 3 | 3250615660916 |
Other Technical data
| With remote signalling contact | Yes |
| Suitable for outdoor use | No |
| Exhausting | No |
| Signalling at the device | Optic |
| Integrated backup fuse | No |
| System configuration DC | No |
| System configuration IT | No |
| System configuration TN | No |
| System configuration TN-C | No |
| System configuration TN-S | No |
| System configuration TT | No |
| System configuration other | No |
| System configuration TN-C-S | No |
Description
SPD 3P pluggable 75kA class 1 with end of life indicator and remote contact TNC
