Switching power supply unit 12V DC
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | Switching power supply unit 12V DC |
| Brand | ELTAKO |
| Country of origin* | CN |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8504 3180 00 |
| ETIM | EC002540 |
| Width | 45 mm |
| Height | 45 mm |
| Depth | 33 mm |
| Voltage type of supply voltage | AC |
| Power output | 6 W |
| Rail mounting possible | No |
| Wall mounting possible | Yes |
| 1st secondary output voltage | 24 V |
| Rated supply voltage at AC 50 Hz | 230 V |
| Max. output current 1 | 1 A |
| Nominal value output current 1 | 1 A |
Packing details
| Packing level 1 | 4010312301326, 4010312301326 |
| Packing level 2 | 4010312301326 |
| Packing level 3 | 4010312301326 |
Other Technical data
| Built-in width | 45 mm |
| Modular version | No |
| Suitable for safety functions | No |
| Output voltage stabilized | Yes |
| Type of electric connection | Screw connection |
| Stabilized | Yes |
| Degree of protection (IP) | IP20 |
| Direct mounting possible | No |
| Secondary voltage adjustable | No |
| Short-circuit-proof | Yes |
| Nominal value output voltage 1 | 24 V |
Downloads
Description
Switching power supply unit. Rated capacity 6W. Standby loss 0.1 watt only. Built-in device for installation. 45mm long, 45mm wide, 33mm deep. Input voltage 230V (-20% up to +10%). Efficiency 82%. Stabilised output voltage ±1%, low residual ripple. Short-circuit proof. Overload protection and over-temperature switch-off by means of swichting off with automatic switching-on after fault clearance (autorecovery function).
