FP 1,27/ 80-MH - SMD male connectors
Order only
Minimal order quantity: 560
Price (excl. VAT):
5,21 €
per pcs
Subtotal: 2 917,60 €
MOQ: 560
EAN: 4055626402994
MPN: 1714923
Box: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | FP 1,27/ 80-MH - SMD male connectors |
| Brand | Phoenix Contact |
| Categories |
PCB Connectors & Terminals
|
| Country of origin | CZ |
| Harmonized System Code | 8536 6930 00 |
| Type of connection | Printed circuit board to cable |
| Rated voltage | 0 V |
| Number of poles | 80 |
| Operating temperature | -55-125 °C |
| Rated surge voltage | 0 kV |
| Type of electric connection | Other |
| Connector model | Fixed connector |
| Angle PCB/contact | Other |
| Rated current In | 1.4 A |
Packing details
| Packing level 1 | 4055626402994, 4055626402994 |
Other Technical data
| Colour housing | Black |
| Contact type | Pin |
| Inflammability class of insulation material according to with UL94 | V0 |
| Material of contact surface | Gold |
| Over voltage category | III |
| Pollution degree | 2 |
| Diameter connection pin | 0 mm |
| Length pin | 0 mm |
| Modular spacing connections | 1.27 mm |
| Number of plug-in contact rows | 2 |
| Type of banding | Other |
| Suitable for PCB thickness | 0 mm |
| Modular spacing contacts | 1.27 mm |
| Material insulation body | Other |
| Type of PCB fastening | Other |
Description
SMD male connector, nominal current: 1.4 A, Test voltage: 500 V AC, number of positions: 80, pitch: 1.27 mm, color: black, contact surface: Gold, type of contact: Male connector, mounting: SMD soldering
