Single-pole earthing and short-circuit. cable 25mm² with crimped cable

Name: Single-pole earthing and short-circuit. cable 25mm² with crimped cable
Brand: Dehn
Price: 1008.270 EUR
Availability: PreOrder

Order only

Price (excl. VAT):

1 008,27 €

This price is valid until 30.06.26

EAN: 4013364165564

MPN: VF33XR2

Package: 1

Estimate delivery time at our warehouse (approx.): 2 weeks

Technical Information

Item condition	New
Manufacture name	Single-pole earthing and short-circuit. cable 25mm² with crimped cable
Brand	Dehn
Categories	Electrical Safety Equipment
Country of origin*	DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8535 9000 00
Model	Cable
Number of poles	1
Max. short circuit current	7 kA
Wire cross section, phase-side	25 mm²
Wire cross section, earth-side	25 mm²

Packing details

Packing level 1

4013364165564, 4013364165564

Other Technical data

Material	Copper
Length 1-pole rope	5000 mm
Connecting part, phase-side	Other
Connecting part, earth-side	Earthing clamp

Downloads

Product data sheet Deep link REACH

Description

Single-pole earthing and short-circuiting device according to EN/IEC 61230 (DIN VDE 0683-100), cable cross-section: 25 mm², maximum short-circuit current / duration: 7.5 kA / 0.5 s - 2.5; length A = 5000 mm; phase cable equipped with 1x phase screw clamp, clamping range Ø4...30 mm (Part No. 784 201) and earth cable equipped with 1x earth milling clamp for flat profiles up to 40 mm with tommy bar (Part No. 792 190).
