Shunt release for NZM4, configurable relays, 2NO, 110-130AC, Push-in terminals
Order only
Price (excl. VAT):
151,92 €
EAN: 4015081877416
MPN: 189746
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Shunt release for NZM4, configurable relays, 2NO, 110-130AC, Push-in terminals |
| Brand | EATON |
| Categories |
Trip & Release Units
|
| Country of origin* | RO |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8538 9099 00 |
| Type of electric connection | Spring clamp connection |
| Rated control supply voltage at AC 50 Hz | 110-130 V |
| Rated control supply voltage at AC 60 Hz | 110-130 V |
| Rated control supply voltage at DC | 0 V |
| Initial value of the undelayed short-circuit release - setting range | 0 A |
| End value adjustment range undelayed short-circuit release | 0 A |
| Voltage type for actuating | AC |
Packing details
| Packing level 1 | 4015081877416 |
Other Technical data
| Suitable for off-load switch | Yes |
| Suitable for overload relay | No |
| Suitable for motor safety switch | Yes |
| Suitable for power circuit breaker | No |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 2 |
| Number of contacts as change-over contact | 0 |
Description
Optional accessories for the circuit-breaker series NZM offers a comprehensive portfolio of application options for use world wide. The mounting is always flexible and easy thanks to the modular function groups. Notes: Shunt releases with two relays. Switches are tripped by a voltage pulse or by the application of uninterrupted voltage. For signalizing commands or different states of the circuit-breaker. Two relays per unit. Actuation reason can be configured in the trip unit. Configuration via communication or circuit breaker display or front USB connection and Eaton Power Xpert Protection Manager . When the shunt release is live, contact with the circuit-breaker's main contacts on switching on is reliably prevented. Only suitable for use in conjunction with circuit-breakers with electronic releases. Shunt release relais modules cannot be installed simultaneously with early-make contact NZM…-XHIV, or untervoltage release NZM…-XU…, or shunt release NZM…-XA… Relay coil actuated by trip unit. Relay contact for control wiring. Control wiring to push-in terminals. Cannot be used with PXR10 NZM-AE electronic release.
