Sensor luminaire LED PIR sensor luminaire 8 W
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | Sensor luminaire LED PIR sensor luminaire 8 W |
| Brand | Ensto |
| ETIM | EC002892 |
| Width | 254 mm |
| Colour housing | Grey |
| Colour rendering index CRI | 80-89 |
| Length | 254 mm |
| Height/depth | 90 mm |
| Lamp type | LED exchangeable |
| Impact strength | IK02 |
| Degree of protection (IP) | IP54 |
| Beam angle | Open beam/diffuse |
| Max. system power | 8 W |
| Rated luminous flux according to IEC 62722-2-1 | 800 lm |
Packing details
| Packing level 1 | 6418677626128, 6418677626128 |
| Packing level 2 | 6418677626128 |
Other Technical data
| Protection class | II |
| Voltage type | AC |
| With movement sensor | Yes |
| Type of grid | None |
| Type of control gear | LED operating device voltage-controlled |
| Built-in diameter | 240 mm |
| With light sensor | No |
| Suitable for suspended mounting | No |
| Housing material | Plastic |
| Suitable for light line configuration | No |
| Suitable for emergency lighting | No |
| Light outlet | Direct |
| Light sharing | Symmetric |
| Material cover | Plastic, opal |
| With light source | Yes |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | No |
| Covering of the luminaire with thermally insulating material possible | Yes |
| Suitable for number of lamps | 1 |
| Suitable for wall mounting | Yes |
| Suitable for built-in mounting | Yes |
| With control gear | Yes |
| Suitable for workplace according to EN 12464-1 | No |
| Suitable for surface mounting | Yes |
| Colour of light | White |
| With air slots | No |
| Rated life time L70/B50 at 25 °C | 100000 h |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | No |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming GPRS | No |
| Dimming LineSwitch | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off | No |
| Dimming phase cut-on | No |
| Dimming programmable | No |
| Dimming RF | No |
| Dimming Sine Wave Reduction | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| No dim function | Yes |
| Dimming depending on control gear | No |
| Dimming DSI | No |
| Suitable for ceiling mounting | Yes |
| Built-in height/depth | 34 mm |
Description
AVR-254 universal luminaires are designed for both wet and dry premises. They can be used both in indoor and outdoor applications. Luminaires fit excellent for bathrooms and toilets, wardrobes, shelters, terraces and vestibules. Luminaires are available in LED-, PIR- and radar-models.
