LED ceiling-recessed luminaire

Compact, pivotable LED recessed ceiling luminaire with linear, synchronously pivotable "Synchro-Gimbal" single light heads; for flexible accent lighting and horizontal planar illumination with high brilliance and very good glare control; linear multifunctional lamp unit is pivotable in/out (±25°); with 6 linear, synchronously pivotable (±25°) single light heads enabling a rotating light beam; precise and uniform light distribution; very good glare control UGR<13; lamp(s): 18W LED1900-940; FLOOD distribution characteristic; reflector: silver with black deco edge, mirrorbrite; Colour rendering Ra > 90, colour temperature 4000 K (neutral white); Chromaticity tolerance (initial MacAdam): 2; Luminaire luminous flux: 1900 lm, Luminaire efficacy: 90 lm/W; service life: 50000 h for luminous flux at 90% of initial value; complete model consisting of luminaire and separate control unit, Slave luminaire for DALI control (DALI only); patented innovative thermal design achieves passive cooling; housing made of die-cast aluminium, black painted; reflector unit made of polycarbonate 2-part: Kopf aluminium-sputtered, facetted mirrorbrite / square base with decorative edge; luminaire wired with halogen-free leads; plug & play cable connection between luminaire unit and control unit; Luminaire input power: 21 W; electrical connection: 4-pole terminal; loop-in/loop-out not possible; mains voltage: 220-240 V / 50/60 Hz ; simple tool-free installation of the linear light heads in the installation frames using CLIX technology, for ceiling thicknesses of 1-25 mm (to be ordered separately); ceiling cut-out: 60x264 mm, recessed depth: 100mm + ceiling thickness; Dimensions: 250 x 47 x 70 mm, weight: 0.6 kg; Note: Different colour combinations (design personalisation) of the individual components can be ordered as a variant via mySUPERSYSTEM INTEGRAL. Note: Installation frames with trim or plaster surround (trimless) must be ordered separately.
