RESI9 2P 40A 300MAS A

Order only Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	RESI9 2P 40A 300MAS A
Brand	Schneider Electric
Country of origin*	ES
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
ETIM	EC000003
Rated current	40 A
Rated voltage	230 V
Rated insulation voltage Ui	440 V
Number of poles	2
Rated fault current	300 A
Leakage current type	A
Selective protection	Yes
Short-circuit breaking capacity (Icw)	6 kA
Surge current capacity	3 kA
Short-time delayed tripping	No
Frequency	50/60 Hz
Rated impulse withstand voltage Uimp	4 kV

Packing details

Packing level 1

3606481905123

Other Technical data

Mounting method	DIN rail
Built-in depth	44 mm
Pollution degree	2
Width in number of modular spacings	2
Degree of protection (IP)	IP20
Connectable conductor cross section solid-core	1-35 mm²
Connectable conductor cross section multi-wired	1-25 mm²
With interlocking device	No
Ambient temperature during operating	-25-60 °C
Additional equipment possible	No

Description

This is a Resi9 RCCB residual current circuit breaker (RCCB). It is a 2P circuit breaker with In rated current of 40A, A-S type protection class and a 30mA earth leakage sensitivity. This product protects against electrical shock by direct or indirect contact and fire hazards. As an high sensitivity residual current circuit breaker, it is recommended for all power sockets. It is also compulsory for all equipment in bathrooms, outdoors. The Resi9 is targeted to the residential market for individual and collective buildings. This product is compliant with EN/IEC 61008-2-1 standard. The (Inc/IΔc) conditional rated short circuit current is 6000 A. The (Im/IΔm) rated making and breaking capacity is 500A. The electrical endurance is up to 10000 cycles. The mechanical endurance is up to 20000 cycles. The Ue operational voltage is 230VAC. It is DIN rail mountable. The width in 9mm pitches is 4. The product colour is white (RAL9003). The dimensions are (W) 36mm x (H) 81mm x (D) 73mm. It has an IP20 degree of protection. It becomes IP40 once in modular enclosure according to IEC/EN 60529 standard. The operating temperature is from -25°C to 40°C. The storage temperature is from -40°C to 80°C.
