Relay interface module 38.61 1CO 6A 48V UC screwless
Order only
Minimal order quantity: 10
Price (excl. VAT):
29,05 €
per pcs
Subtotal: 290,50 €
MOQ: 10
EAN: 8012823231952
MPN: 386100480060
Package: 10
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | Relay interface module 38.61 1CO 6A 48V UC screwless |
| Brand | FINDER |
| Categories |
Electromechanical Relays
|
| Harmonized System Code | 8536 4900 00 |
| ETIM | EC001437 |
| Nominal current | 6 A |
| Type of switch contact | Single contact |
| Type of electric connection | Spring clamp connection |
| Rated control supply voltage at AC 50 Hz | 48 V |
| Degree of protection (IP) | IP20 |
| With LED indication | Yes |
| Voltage type for actuating | AC/DC |
| Number of contacts as normally closed contact | 0 |
| Number of contacts as normally open contact | 0 |
Packing details
| Packing level 1 | 8012823231952 |
Other Technical data
| Width | 6.2 mm |
| Height | 93.6 mm |
| Depth | 72.5 mm |
| With detachable clamps | No |
| Drive, polarization | Polarity free |
| Drive, switching attitude | Mono stable |
| With forced-guided contacts | No |
| Complete with socket | Yes |
| Rated control supply voltage at AC 60 Hz | 48 V |
| Rated control supply voltage at DC | 48 V |
| Material of contact surface | Untreated |
| Material contact | Other copper alloys |
| Number of contacts as change-over contact | 1 |
| Material of contact insert | Thermoplastic |
Downloads
Description
Relay interface modules EMR (A): 6 A. Nr.contacts: 1 Contacts configuration: CO Contact Material: AgNi Type of electric connection: Spring clamp connection Coil version: AC/DC Volt AC: 48 V. Volt DC: 48 V. Polarity free Mono stable Protection category: IP20 With LED indication: yes Accessories: Jumper link;plastic separator
Alternative EAN
Order only
6,18 €
Subtotal: 618,00 €
MOQ: 100
EAN: 5900005241130
MPN: 863769
Package: 1
Box: 20
