theRonda S360 DALI-2 S UP WH
Order only
Price (excl. VAT):
97,69 €
EAN: 4003468200384
MPN: 2080590
Package: 1
Box: 60
Estimate delivery time at our warehouse (approx.):
2-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | theRonda S360 DALI-2 S UP WH |
| Brand | Theben |
| Categories |
Motion & Presence Sensors
|
| Country of origin | HU |
| Harmonized System Code | 8536 5080 00 |
| Mounting method | Flush mounted (plaster) |
| Colour | White |
| Width | 110 mm |
| Model | Presence detector |
| Height | 83 mm |
| Depth | 110 mm |
| Connection type | Screwed terminal |
| Max. transmission range frontally | 4 m |
| Max. transmission range sideways | 4 m |
| Scan angle | 360 ° |
| Degree of protection (IP) | IP54 |
| Response value luminosity adjustable | Yes |
| Optimum mounting height | 2.5 m |
| Max. presence range | 13 m² |
| Sensor type | Passive infrared |
Packing details
| Packing level 1 | 4003468200384 |
| Packing level 2 | 4003468200384 |
Other Technical data
| Halogen free | No |
| Surface protection | Untreated |
| Creep-under protection | No |
| Built-in depth | 37 mm |
| With remote control | No |
| Diameter | 110 mm |
| Built-in width | 48 mm |
| Built-in diameter | 48 mm |
| Staircase monitoring | Yes |
| Bridging switch | No |
| Suitable for wireless transmission | No |
| Material quality | Thermoplastic |
| Temperature | -15-50 °C |
| Material | Plastic |
| Response value sensitivity adjustable | Yes |
| Dim function with dimmer basic element | No |
| Response value luminosity | 10-10000 lx |
| Suitable for C-load | No |
| Diameter detection range on floor | 8 m |
| Remote operation | Yes |
| HVAC-control | No |
| Constant light control | Yes |
| Substation input | Yes |
| RAL-number (similar) | 9010 |
| With signal unit | No |
| Teach-function for response value luminosity | Yes |
| Networkable | Yes |
| Forced switch off | No |
| Impact strength | IK04 |
| With alarm function | No |
| Transparent | No |
| Animal zone | No |
| Surface finishing | Matt |
| Detection angle horizontal | 0-360 ° |
| Suitable for wall mounting | No |
| With DALI interface | Yes |
| Forced switch on | No |
| Min. starting current | 0.1 A |
| Min. depth of built-in installation box | 46 mm |
| Suitable for ceiling mounting | Yes |
| Anti-bacterial treatment | No |
Description
Aanwezigheidssensor voor plafondmontage, DALI-2 gecertificeerd, rond detectiebereik 360 °, tot Ø 9 m (64 m2), mixlichtmeting 1-voudig, 1 voorbeeld voor aanwezigheid, 1 voorbeeld voor lichtsterkte, geeft informatie over "aanwezigheid" en "lichtsterkte" "Als DALI-telegram volgens IEC 62386 deel 303/304, eenvoudige aanpassing van de lichtsterktemeting, testmodus om functie en detectiebereik te controleren, detectiegevoeligheid instelbaar, een multi-master applicatiecontroller is vereist voor inbedrijfstelling / besturing en configuratie, deze moet delen 101/103 en optioneel 301/303/304 volgens IEC 62386 ondersteunen
