PLD - Floor standing encl.polyester w/plinth open bottom 850x590x320 IP43 DIN0

Order only

Price (excl. VAT):

691,73 €

This price is valid until 24.12.25

EAN: 3606480776380

MPN: NSYPLD860G

Package: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	PLD - Floor standing encl.polyester w/plinth open bottom 850x590x320 IP43 DIN0
Brand	Schneider Electric
Categories	Electrical Enclosures
Country of origin	ES
Degree of protection (IP)	IP43
Thermal dissipation (Delta T = 20 K) according to IEC/TR 60890	0 W
Max. permissible load of the enclosure according to IEC 62208	0 N
Max. permissible load of the door(s) according to IEC 62208	0 N

Packing details

Packing level 1

3606480776380

Other Technical data

Colour	Grey
Width	590 mm
Height	850 mm
Depth	320 mm
RAL-number	7035
With mounting plate	No
Number of doors	1
Number of locks	1
EMC-version	No
With glazed door	No
Material quality	Polyester
Material	Plastic
Impact strength	IK10
Suitable for outdoor set-up	Yes
Suitable for metrical mounting	Yes
Mounting plate depth-adjustable	No
With ventilation door	No
Surface finishing	Untreated
With rear door	No
Suitable for wall built-in	No
Pitched roof	Yes
Pole fastening	No
Degree of protection (NEMA)	4X
Max. permissible load of the mounting plate according to IEC 62208	0 N

Downloads

ECOP (Environmental Code of Practice) Declaration DOC CE (Declaration of conformity CE) Technical manual

Description

Thalassa PLD floor standing polyester enclosure open bottom with plinth. 850x 590x 320 mm. DIN/Distribution enclosure type. DIN0 fuse size. Key lock is 1242E lock type. 1 door. Reversible 180° opening. Accessible front and bottom. Polyester reinforced with fibreglass. Grey RAL 7035. IP43 (IP54 w/sealing kit), IK10. 960°C fire resistance.
