Dehn

Pipe clamp D 27-89mm StSt w. connection f. Rd 6-8/10 or 4-50mm²

Order only
Price (excl. VAT):
6,72 €
This price is valid until 24.12.25
EAN: 4013364239685
MPN: 540104
Package: 1
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name Pipe clamp D 27-89mm StSt w. connection f. Rd 6-8/10 or 4-50mm²
Brand Dehn
Categories Earthing Products
Country of origin* DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code 8538 9099 00
Surface protection Untreated
Material Stainless steel V2A
Clamping/chucking range 27-89 mm
Explosion-proof Yes
Min. clamping range inch 3/4 inch
Max. clamping range inch 3 inch

Packing details

Packing level 1 4013364239685, 4013364239685

Downloads

Product data sheet Dimensioned drawing

Description

Pipe clamp, sescured against self-loosening, according to EN 62561-1, for integrating pipes into the protective and functional equipotential bonding according to IEC 60364-4-41/60364-5-54 (DIN VDE 0100 Part 410/540) and lightning equipotential bonding according to IEC/EN 62305-3. Complete with continuously adjustable StSt tensioning strap, to connect 1 conductor Rd D10 mm or 1-2 conductors Rd D6-8 mm or 4-50 mm² (solid / stranded).
