Photoelectric Sensor Opposed Mode Sensor (Emitter) S12-2NAEJ-2M
Order only
Price (excl. VAT):
56,76 €
EAN: 0662488874100
MPN: 3087410
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Photoelectric Sensor Opposed Mode Sensor (Emitter) S12-2NAEJ-2M |
| Brand | Banner |
| Categories |
Photoelectric Sensors
|
| Country of origin | CN |
| Harmonized System Code | 8536 5019 00 |
| Housing material | Plastic |
| Ambient temperature | -25 °C |
| Type of light | Infrared light |
| Wavelength of the sensor | 880 nm |
| Degree of protection (IP) | IP67 |
| Rated switching distance | 20 mm |
Packing details
| Packing level 1 | 0662488874100, 0662488874100 |
Other Technical data
| Suitable for safety functions | No |
| With time function | No |
| Type of electric connection | Cable |
| Setting procedure | Other |
| Construction type housing | Cylinder, screw-thread |
| Min. reflector distance | 0 mm |
| With monitoring function downstream switching devices | No |
| With restart blockage | No |
| Response time | 11 ms |
| Pre failure notice | No |
| Material of optical surface | Other |
| Material of cable sheath | Polyvinyl chloride (PVC) |
| Analogue output 0 V ... 10 V | No |
| Analogue output 0 mA ... 20 mA | No |
| Analogue output -10 V ... +10 V | No |
| Analogue output 4 mA ... 20 mA | No |
| Diameter sensor | 12 mm |
| With communication interface analogue | No |
| With communication interface AS-Interface | No |
| With communication interface CANOpen | No |
| With communication interface DeviceNet | No |
| With communication interface Ethernet | No |
| With communication interface INTERBUS | No |
| With communication interface PROFIBUS | No |
| With communication interface RS-232 | No |
| With communication interface RS-422 | No |
| With communication interface RS-485 | No |
| With communication interface SSD | No |
| With communication interface SSI | No |
| Length of sensor | 30.4 mm |
| Max. switching distance | 20 mm |
| With reflector | No |
| With other analogue output | No |
Downloads
Description
Foto-elektrische sensor, zender-ontvanger systeem (zender), Bedrijfsspanning 10…30 VDC, max. reikwijdte 20 mm, Kabellengte 2 m, 2 m kabel, 3-polig, voedingsspanning 10‐30 VDC, lichtschakelend, PNP
