Photoelectric Sensor Bifurcated Retroreflective Sensor SLM10B6
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
Price by request
EAN: 0662488749651
MPN: 3074965
Package: 1
Estimate delivery time at our warehouse (approx.):
By request
Technical Information
| Item condition | New |
| Manufacture name | Photoelectric Sensor Bifurcated Retroreflective Sensor SLM10B6 |
| Brand | Banner |
| Categories |
Photoelectric Sensors
|
| Country of origin | CN |
| Harmonized System Code | 8536 5019 00 |
| Switching frequency | 1000 Hz |
| Response time | 0.5 ms |
| Max. switching distance | 10 mm |
| Rated switching distance | 10 mm |
| Fork width | 10 mm |
Packing details
| Packing level 1 | 0662488749651, 0662488749651 |
Other Technical data
| Housing material | Metal |
| Suitable for safety functions | No |
| Ambient temperature | -20 °C |
| With time function | No |
| Type of electric connection | Cable |
| Type of switching output | PNP/NPN |
| Type of switch function | Normally open contact (NO) |
| Construction type housing | Special construction |
| Type of light | Polarity free red light |
| With monitoring function downstream switching devices | No |
| With restart blockage | No |
| Pre failure notice | No |
| Wavelength of the sensor | 680 nm |
| Material of optical surface | Plastic |
| Material of cable sheath | Polyvinyl chloride (PVC) |
| Degree of protection (IP) | IP67 |
| Analogue output 0 V ... 10 V | No |
| Analogue output 0 mA ... 20 mA | No |
| Analogue output -10 V ... +10 V | No |
| Analogue output 4 mA ... 20 mA | No |
| Width sensor | 12 mm |
| Height of sensor | 42 mm |
| With communication interface analogue | No |
| With communication interface AS-Interface | No |
| With communication interface CANOpen | No |
| With communication interface DeviceNet | No |
| With communication interface Ethernet | No |
| With communication interface INTERBUS | No |
| With communication interface PROFIBUS | No |
| With communication interface RS-232 | No |
| With communication interface RS-422 | No |
| With communication interface RS-485 | No |
| With communication interface SSD | No |
| With communication interface SSI | No |
| Length of sensor | 80 mm |
| With reflector | No |
| With other analogue output | No |
Downloads
Description
Foto-elektrische sensor, sleufsensor, Bedrijfsspanning 10…30 VDC, max. reikwijdte 10 mm, Kabellengte 2 m, kabel, PVC, 2 m, beschermingsgraad IP67, gevoeligheidsinstelling met potentiometer, bedrijfsspanning: 10…30 VDC, bipolaire schakeluitgang, helder- of donkerschakelend
