PFGCM-25/2/003-A Eaton Moeller series xPole - PFGCM RCCB
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | PFGCM-25/2/003-A Eaton Moeller series xPole - PFGCM RCCB |
| Brand | EATON |
| ETIM | EC000003 |
| Voltage type | AC |
| Rated current | 25 A |
| Rated voltage | 230 V |
| Rated insulation voltage Ui | 440 V |
| Number of poles | 2 |
| Rated fault current | 0.03 A |
| Leakage current type | A |
| Selective protection | No |
| Short-circuit breaking capacity (Icw) | 10 kA |
| Surge current capacity | 0.25 kA |
| Short-time delayed tripping | No |
| Frequency | 50 Hz |
| Rated impulse withstand voltage Uimp | 4 kV |
Packing details
| Packing level 1 | 4015081088782 |
| Packing level 2 | 9007912851165, 9007912851165 |
Other Technical data
| Mounting method | DIN rail |
| Built-in depth | 69.5 mm |
| Pollution degree | 2 |
| Width in number of modular spacings | 2 |
| Explosion-proof | No |
| Degree of protection (IP) | IP20 |
| Connectable conductor cross section solid-core | 1.5-35 mm² |
| Connectable conductor cross section multi-wired | 1.5-16 mm² |
| With interlocking device | Yes |
| Ambient temperature during operating | -25-55 °C |
| Additional equipment possible | Yes |
Description
Residual current circuit breaker (RCCB), 25A, 2pole, 30mA, type A
