PTSPL-6/1-2X2 2,9 R32 - PCB terminal block

Name: PTSPL-6/1-2X2 2,9 R32 - PCB terminal block
Brand: Phoenix Contact
Price: 0.510 EUR
Availability: PreOrder

Order only Minimal order quantity: 250

Price (excl. VAT):

0,51 € per pcs

This price is valid until 24.12.25

Subtotal: 127,50 € MOQ: 250

EAN: 4046356739993

MPN: 1704837

Box: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	PTSPL-6/1-2X2 2,9 R32 - PCB terminal block
Brand	Phoenix Contact
Categories	PCB Connectors & Terminals
Country of origin	DE
Harmonized System Code	8536 9010 00
Rated voltage	0 V
Number of levels	1
Rated surge voltage	0 kV
Angle PCB/conductor connection	Other
Rated current In	41 A
Number of electrical connections	1

Packing details

Packing level 1

4046356739993, 4046356739993

Other Technical data

Height	12.9 mm
Operating temperature	-40-100 °C
Over voltage category	III
Pollution degree	2
Connection type conductor	Spring clamp connection
Connection type PCB	THR connection
Diameter connection pin	1.3 mm
Length pin	2.9 mm
Material connection surface	Tin
Modular spacing connections	0 mm
Type of banding	Blister girdle (for SMD)
Connectable conductor cross section fine-strand without cable end sleeve	2.5-6 mm²
Type of PCB fastening	Connecting contact

Description

PCB terminal block for tin-plated flexible cables, e.g., type PV 1-F, nominal current: 41 A, number of positions: 1, connection method: spring-cage connection, mounting: THT/THR, for user information for through-hole reflow technology, go to: combicon.com
