Phoenix Contact

FK-MPT 0,5/15-3,5-H - PCB terminal block

Order only Minimal order quantity: 50
Price (excl. VAT):
1,80 € per pcs
This price is valid until 24.12.25
Subtotal: 90,00 € MOQ: 50
EAN: 4017918591342
MPN: 1928893
Box: 1
Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition New
Manufacture name FK-MPT 0,5/15-3,5-H - PCB terminal block
Brand Phoenix Contact
Categories PCB Connectors & Terminals
Country of origin IN
Harmonized System Code 8536 9010 00
Rated voltage 250 V
Number of levels 1
Rated surge voltage 2.5 kV
Angle PCB/conductor connection Other
Rated current In 4 A
Number of electrical connections 30

Packing details

Packing level 1 4017918591342, 4017918591342

Other Technical data

Height 12.5 mm
Colour housing Green
Operating temperature -40-100 °C
Inflammability class of insulation material according to with UL94 V0
Over voltage category III
Pollution degree 2
Connection type conductor Spring clamp connection
Diameter connection pin 1.2 mm
Length pin 4 mm
Material connection surface Tin
Modular spacing connections 3.5 mm
Type of banding Carton (for SMD)
Connectable conductor cross section solid-core 0.12-0.5 mm²
Connectable conductor cross section multi-wired 0.5 mm²
Material insulation body Other
Type of PCB fastening Connecting contact

Description

PCB terminal block, nominal current: 4 A, rated voltage (III/2): 250 V, nominal cross section: 0.5 mm², number of potentials: 15, number of rows: 1, number of positions per row: 15, product range: FK-MPT 0,5/..-H, pitch: 3.5 mm, connection method: Push-in spring connection, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: green, Pin layout: Linear pinning, Solder pin [P]: 4 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard
