GICV 2,5/ 3-G-7,62 - PCB header

Name: GICV 2,5/ 3-G-7,62 - PCB header
Brand: Phoenix Contact
Price: 0.920 EUR
Availability: PreOrder

Order only Minimal order quantity: 50

Price (excl. VAT):

0,92 € per pcs

This price is valid until 24.12.25

Subtotal: 46,00 € MOQ: 50

EAN: 4017918050818

MPN: 1828922

Box: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	GICV 2,5/ 3-G-7,62 - PCB header
Brand	Phoenix Contact
Categories	PCB Connectors & Terminals
Country of origin	DE
Harmonized System Code	8536 6930 00
Type of connection	Printed circuit board to cable
Rated voltage	630 V
Number of poles	3
Operating temperature	-40-100 °C
Rated surge voltage	6 kV
Type of electric connection	Other
Connector model	Fixed connector
Angle PCB/contact	Other
Rated current In	12 A

Packing details

Packing level 1

4017918050818, 4017918050818

Other Technical data

Colour housing	Green
Contact type	Bus
Type of fastening	Other
Inflammability class of insulation material according to with UL94	V0
Material of contact surface	Tin
Over voltage category	III
Pollution degree	2
Diameter connection pin	1.4 mm
Length pin	3.6 mm
Modular spacing connections	7.62 mm
Number of plug-in contact rows	1
Type of banding	Carton (for SMD)
Suitable for PCB thickness	0 mm
Modular spacing contacts	7.62 mm
Material insulation body	Other
Type of PCB fastening	Other

Description

PCB headers, nominal cross section: 2.5 mm², color: green, nominal current: 12 A, rated voltage (III/2): 630 V, contact surface: Tin, type of contact: Female connector, number of potentials: 3, number of rows: 1, number of positions: 3, number of connections: 3, product range: GICV 2,5/..-G, pitch: 7.62 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.6 mm, number of solder pins per potential: 2, plug-in system: COMBICON MSTB 2,5, Pin connector pattern alignment: Standard, locking: without, mounting: without, type of packaging: packed in cardboard
