PCB coupler 3p plug, horiz., 1-latch, wht
Order only
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | PCB coupler 3p plug, horiz., 1-latch, wht |
| Brand | Ensto |
| ETIM | EC002566 |
| Model | Plug |
| Connection type | Soldering connection |
| Locking mechanism | Integrated in plug-in connector |
| Rated current | 20 A |
| Rated voltage | 250 V |
| Number of poles | 3 |
| Housing material | Polyamide (PA) |
| Contact material | CuZn |
| Degree of protection (IP) | IP20 |
Packing details
| Packing level 1 | 6418677681325 |
| Packing level 2 | 6418677681325 |
| Packing level 3 | 6418677681325 |
Other Technical data
| Halogen free | Yes |
| Angle of plug | Angled |
| Mechanical coding | Yes |
| Built-in version | Built-in part/plug-in connection |
Description
Printed circuit board couplers are designed for internal connections in the device. The range includes models for both horizontal and vertical mounting.
