PTDA 1,5/ 3-PH-3,5 BU - PCB connector

In stock: No Vendor stock: No Minimal order quantity: 250

Price (excl. VAT):

0,84 € per pcs

This price is valid until 24.12.25

Subtotal: 210,00 € MOQ: 250

EAN: 4055626732428

MPN: 1066270

Box: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	PTDA 1,5/ 3-PH-3,5 BU - PCB connector
Brand	Phoenix Contact
Categories	Industrial connections and blocks
Country of origin	BG
Harmonized System Code	8536 6990 00
Type of connection	Other
Colour housing	Blue
Rated voltage	240 V
Number of poles	0
Contact type	Bus
Housing material	Other
Coating housing	Other
Operating temperature	-40-100 °C
Inflammability class of insulation material according to with UL94	V0
Rated surge voltage	2.5 kV
Type of electric connection	Spring clamp connection
Material of contact surface	Tin
Over voltage category	III
Pollution degree	2
Connectable cable type	Other
Modular spacing connections	3.5 mm
Number of plug-in contact rows	1
Modular spacing contacts	3.5 mm
Connectable conductor cross section solid-core	0.2-1.5 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.2-1.5 mm²
With protective conductor	No
Material insulation body	Other
Material contact	Copper
Angle contact/conductor connection	Other
Rated current In	8 A

Packing details

Packing level 1

4055626732428

Description

PCB connector, nominal cross section: 1.5 mm², color: blue, nominal current: 8 A, rated voltage (III/2): 240 V, contact surface: Tin, type of contact: Female connector, number of rows: 1, number of positions: 3, product range: PTDA 1,5/..-PH, pitch: 3.5 mm, connection method: Push-in spring connection, conductor/PCB connection direction: 45 °, pin layout: Linear double pinning, plug-in system: COMBICON PST 1,0, locking: without, mounting: without, type of packaging: packed in cardboard
