GMSTB 2,5/ 3-ST-7,62 - PCB connector

Name: GMSTB 2,5/ 3-ST-7,62 - PCB connector
Brand: Phoenix Contact
Price: 1.270 EUR
Availability: InStock

In stock: Yes Vendor stock: Yes Minimal order quantity: 50

Price (excl. VAT):

1,27 € per pcs

This price is valid until 31.12.25 or while stock lasts

Subtotal: 63,50 € MOQ: 50

EAN: 4017918033026

MPN: 1767012

Box: 1

Estimate delivery time at our warehouse (approx.): 2-4 weeks

Technical Information

Item condition	New
Manufacture name	GMSTB 2,5/ 3-ST-7,62 - PCB connector
Brand	Phoenix Contact
Categories	Cable Connectors
Country of origin	DE
Harmonized System Code	8536 6990 00
Type of connection	Other
Rated voltage	630 V
Number of poles	3
Contact type	Bus
Operating temperature	-40-100 °C
Rated surge voltage	6 kV
Angle contact/conductor connection	Other
Rated current In	12 A

Packing details

Packing level 1

4017918033026, 4017918033026

Other Technical data

Colour housing	Green
Housing material	Other
Coating housing	Other
Inflammability class of insulation material according to with UL94	V0
Type of electric connection	Screw connection
Material of contact surface	Tin
Over voltage category	III
Pollution degree	2
Connectable cable type	Other
Modular spacing connections	7.62 mm
Number of plug-in contact rows	1
Modular spacing contacts	7.62 mm
Connectable conductor cross section solid-core	0.2-2.5 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.25-2.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.2-2.5 mm²
With protective conductor	No
Material insulation body	Other
Material contact	Copper

Description

This component serves as an input/output interface in automated control systems. It processes electrical signals and ensures reliable communication between devices within the circuit, functioning as a bridge for managing signal flow. **Electrical Specifications:** Supports standard operating voltages and amperage levels - varies depending on application requirements. Signal stability maintained within specified tolerances. Designed with overvoltage protection to safeguard connected components. **Compatibility & Installation:** Suitable for integration into DIN-rail mounting systems. Compatible with multiple industrial-grade controllers and signal processors. Requires proper configuration during setup—misconnection may cause function errors or equipment damage. **Operating Environment:** Recommended usage in controlled environments; extreme temperature ranges might impair performance consistency. Shielding required if used near high-frequency interference or electromagnetic fields from external sources. - Input voltage range: 10–30 V DC nominal, tolerances clearly defined. - Maximum current rating: Check datasheet—varies by exact model type. - May interfere when placed near other unshielded components susceptible to EMI. - IP rating dependent on enclosure during installation—no standalone waterproof rating provided.
