Optocoupler module Nominal input voltage: 24 VDC Output voltage range:
Order only
Minimal order quantity: 10
Not Available
Estimate delivery time to our warehouse: By request
Technical Information
| Item condition | New |
| Manufacture name | 859-794 Optocoupler module; Nominal input voltage: 24 VDC; Output voltage range: 9 … 60 VDC |
| Brand | WAGO |
| Country of origin* | CN |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8536 5005 00 |
| ETIM | EC001504 |
| Type of voltage (input voltage) | DC |
| Type of digital output | Electronic |
| Input voltage | 16-30 V |
| Output voltage | 9-60 V |
| Type of output voltage | DC |
Packing details
| Packing level 1 | 4055143606325 |
| Packing level 2 | 4055143606325 |
Other Technical data
| Rated operation current Ie | 0.1 A |
| With LED indication | Yes |
Description
Optocoupler module Nominal input voltage: 24 VDC Output voltage range: 9 … 60 VDC Limiting continuous current: 0.1 A Railway Module width: 6 mm
