Z-MS-40/3 Motor-Protective Circuit-Breakers, 25-40A, 3p

In stock: Yes Vendor stock: Yes Minimal order quantity: 1

Price (excl. VAT):

38,70 €

This price is valid until 24.12.25 or while stock lasts

EAN: 4015082484149

MPN: 248414

Package: 1

Box: 40

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	Z-MS-40/3 Motor-Protective Circuit-Breakers, 25-40A, 3p
Brand	EATON
Categories	Motor protection circuit-breakers
Country of origin	RS
Harmonized System Code	8536 2010 00
Rated permanent current Iu	40 A
Number of poles	3
Rated operating voltage	400 V
Overload release current setting	25-40 A
Degree of protection (IP)	IP20
Rated short-circuit breaking capacity lcu at 400 V, AC	10 kA
Adjustment range undelayed short-circuit release	400-520 A

Packing details

Packing level 1	4015082484149
Packing level 2	9007912227960

Other Technical data

Width	54 mm
Height	75 mm
Depth	80 mm
Rated operation power at AC-3, 400 V	18.5 kW
With integrated auxiliary switch	No
With integrated under voltage release	No
With thermal protection	Yes
Type of electrical connection of main circuit	Screw connection
Type of control element	Rocker lever
Switch off technique	Magnetic
Rated operation power at AC-3, 230 V	0 kW
Phase failure sensitive	No
Device construction	Complete device in housing

Description

Motor-protective circuit-breaker with thermal overload release and magnetic short-circuit release, for switching and protecting three-phase motors with outputs of up to 15 kW (380/400 V) or other loads with currents of up to 40 A, can also be used as a main switch, isolating characteristics to IEC/EN 60947, contact position display red/green
