MOTOR PROTECTION SWITCH 13-18A - 2.5 MODULES
Order only
Price (excl. VAT):
68,53 €
EAN: 8034035136689
MPN: GWD6512
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | MOTOR PROTECTION SWITCH 13-18A - 2.5 MODULES |
| Brand | GEWISS |
| Categories |
Motor protection circuit-breakers
|
| Harmonized System Code | 8536 2010 00 |
| Rated permanent current Iu | 18 A |
| Number of poles | 3 |
| Rated operating voltage | 220 V |
| Overload release current setting | 13 A |
| Degree of protection (IP) | IP20 |
| Rated short-circuit breaking capacity lcu at 400 V, AC | 25 kA |
Packing details
| Packing level 1 | 8034035136689, 8034035136689 |
| Packing level 2 | 8034035136689 |
Other Technical data
| Width | 45 mm |
| Height | 89.5 mm |
| Depth | 62 mm |
| With integrated auxiliary switch | No |
| With integrated under voltage release | No |
| With thermal protection | Yes |
| Type of electrical connection of main circuit | Screw connection |
| Type of control element | Push button |
| Switch off technique | Thermomagnetic |
| Phase failure sensitive | Yes |
| Device construction | Complete device in housing |
Downloads
Description
90 AM-serie Modulaire accessoires - De 90 AM serie bestaat naast de gebruikelijke hulpstukken voor alle installatieautomaten, uit een veelvoud aan modulaire accessoires voor de bescherming, bediening, programmering, meting en signalering in elektrische systemen.
