MONITORING RELAY

Order only Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	MONITORING RELAY
Brand	FINDER
ETIM	EC001441
Voltage measuring range	320-460 V
Type of electric connection	Screw connection
Number of contacts as normally closed contact	0

Packing details

Packing level 1

8012823321424

Other Technical data

Width	35 mm
Height	85 mm
Depth	54.5 mm
With detachable clamps	No
Rated control supply voltage at AC 50 Hz	400 V
Rated control supply voltage at AC 60 Hz	400 V
Max. permitted delay-on energization time	0.5 s
Max. permitted off-delay time	12 s
Min. adjustable off-delay time	0.1 s
Voltage type for actuating	AC
Number of contacts as normally open contact	0
Number of contacts as change-over contact	1

Description

Monitoring relays Nr.contacts: 1 Contacts configuration: CO Contact Material: AgSnO2 Coil version: AC Volt AC: 400 V. Voltage measurement range: from 320 to 460 V. With detachable clamps: no Type of electric connection: Screw connection Max. permitted delay-on energization time: 0.5 s. Max. permitted off-delay time: 12 s. (A): 10 Protection Category: IP 20
