Modular SSR.17,5mm.1NO output 5A/230VAC/input 230VAC Zero-crossing (77.01.8.230.8050)

Order only Minimal order quantity: 5

Price (excl. VAT):

52,49 € per pcs

This price is valid until 31.12.25

Subtotal: 262,45 € MOQ: 5

EAN: 8012823350714

MPN: 770182308050

Package: 1

Estimate delivery time at our warehouse (approx.): 1-4 weeks

Technical Information

Item condition	New
Manufacture name	Modular SSR.17,5mm.1NO output 5A/230VAC/input 230VAC Zero-crossing (77.01.8.230.8050)
Brand	FINDER
Categories	Solid State Relays
Country of origin	IT
Harmonized System Code	8536 3010 00
Rated operation current Ie at AC-1	5 A
Voltage type for actuating	AC

Packing details

Packing level 1	8012823350721
Packing level 2	8012823350714

Other Technical data

Number of phases	1
Modular version	Yes
Rated control supply voltage at AC 50 Hz	230 V
Rated control supply voltage at AC 60 Hz	230 V
Operating voltage	48-265 V
Switching at zero-crossing	Yes

Downloads

Product picture

Description

Modular solid state relay Nr.contacts: 1 Contacts configuration: NO Number of phases: 1 Modular version: yes Volt AC: 230 V. Operating voltage: from 48 to 265 V. Rated operation current Ie at AC-1: 5 A. Coil version: AC Switching at zero-crossing: yes Accessories: Adaptor for panel mounting
