Mod.contactor 35mm.2NO+2NC 25A/60VUC, AgNi/Mech.ind./LED (22.34.0.060.1620)

Order only Not Available

Estimate delivery time to our warehouse: By request

Technical Information

Item condition	New
Manufacture name	Mod.contactor 35mm.2NO+2NC 25A/60VUC, AgNi/Mech.ind./LED (22.34.0.060.1620)
Brand	FINDER
ETIM	EC001653
Rated operating voltage	250 V
Voltage type (excitation voltage)	AC/DC
Voltage type (operating voltage)	AC
Degree of protection (IP)	IP20
Rated operation current	25 A
Rated excitation voltage	48-66 V

Packing details

Packing level 1	8012823407173
Packing level 2	8012823407166

Other Technical data

Max. incandescent lamp load	800 W
Max. load fluorescent lamp	200 VA
Additional equipment possible	Yes
Number of contacts as normally closed contact	2
Number of contacts as normally open contact	2

Downloads

Product picture

Description

Modular contactors Nr.contacts: 4 Contacts configuration: 2NO + 2NC Contact Material: AgNi Rated operating voltage: 250 V. Max. incandescent lamp load: 800 W. Max. load fluorescent lamp: 200 VA. Voltage type (excitation voltage): AC/DC Rated excitation voltage: from 48 to 66 V. Voltage type (operating voltage): AC Rated operation current: 25 A. Additional equipment possible: yes Protection Category: IP 20 Options: Mechanical indicator + LED Accessories: Adaptor for panel mounting;jumper link
