Miniature circuit breaker 1P B10 10kA 1M

Order only Minimal order quantity: 6

Price (excl. VAT):

2,72 €

This price is valid until 31.12.26

Subtotal: 16,32 € MOQ: 6

EAN: 8011564222328

MPN: GW92506

Package: 1

Box: 24

Pallet: 2304

Estimate delivery time to our warehouse: In stock - Ready to ship

Technical Information

Item condition	New
Manufacture name	Miniature circuit breaker 1P B10 10kA 1M
Brand	GEWISS
Categories	Circuit breakers 10A
Harmonized System Code	8536 2010 00
Rated current	10 A
Rated voltage	400 V
Release characteristic	B
Width in number of modular spacings	1
Number of poles (total)	1
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	10 kA

Packing details

Packing level 1	8011564222328
Packing level 2	8011564222328
Packing level 3	8011564574847
Packing level 4	8011564222328

Other Technical data

Voltage type	AC
Built-in depth	72 mm
Frequency	50-60 Hz
Rated insulation voltage Ui	500 V
Current limiting class	3
Over voltage category	3
Pollution degree	3
Explosion-proof	No
Degree of protection (IP)	IP20
Number of protected poles	1
Concurrently switching neutral conductor	No
Connectable conductor cross section solid-core	35 mm²
Connectable conductor cross section multi-wired	35 mm²
Ambient temperature during operating	-25-60 °C
Flush-mounted installation	No
Additional equipment possible	Yes
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	0 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	15 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	0 kA
Rated impulse withstand voltage Uimp	4 kV

Downloads

Product data sheet

Description

90 MCB Range Modular circuit breakers for circuit protection - The 90 MCB range meets any requirement for protection against overcurrent and shortcircuit, for all domestic, commercial and industrial applications.The range comprises MTC, compact miniature circuit breakers (from 2 to 32 A, curves B and C up to 10 kA) MT traditional miniature circuit breakers (from 1 to 63 A, curves B, C and D up to 25 kA) MTHP High-Power Miniature circuit breakers (from 20 to 125 A, curves C and D up to 25 kA).
