AZ-3-C100 Miniature circuit breaker (MCB), 100A, 3p, C-Char
In stock
In vendor's stock
Minimal order quantity: 4
Price (excl. VAT):
96,18 €
Subtotal: 384,72 €
MOQ: 4
EAN: 4015082118068
MPN: 211806
Package: 1
Box: 4
Estimate delivery time to our warehouse: In stock - Ready to ship
Technical Information
| Item condition | New |
| Manufacture name | AZ-3-C100 Miniature circuit breaker (MCB), 100A, 3p, C-Char |
| Brand | EATON |
| Categories |
Circuit breakers 100A
|
| Country of origin* | CZ |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Harmonized System Code | 8536 2090 00 |
| Rated current | 100 A |
| Rated voltage | 400 V |
| Release characteristic | C |
| Width in number of modular spacings | 4.5 |
| Number of poles (total) | 3 |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V | 0 kA |
Packing details
| Packing level 1 | 4015082118068 |
| Packing level 2 | 9008790880599 |
| Packing level 3 | 9008790884351 |
Other Technical data
| Voltage type | AC |
| Built-in depth | 75 mm |
| Frequency | 50-60 Hz |
| Rated insulation voltage Ui | 440 V |
| Current limiting class | 3 |
| Over voltage category | 3 |
| Pollution degree | 2 |
| Explosion-proof | No |
| Degree of protection (IP) | IP20 |
| Number of protected poles | 3 |
| Concurrently switching neutral conductor | No |
| Connectable conductor cross section solid-core | 2.5-50 mm² |
| Connectable conductor cross section multi-wired | 2.5-50 mm² |
| Ambient temperature during operating | -25-55 °C |
| Flush-mounted installation | No |
| Additional equipment possible | Yes |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V | 0 kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V | 20 kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V | 20 kA |
| Rated impulse withstand voltage Uimp | 4 kV |
Description
Miniature circuit breaker (MCB) AZ, 3 pole, Tripping characteristic: C, Rated current In: 100 A, Switchgear for industrial and advanced commercial applications
