Miniature Circuit Breaker 3A, 10kA, 1 pole, B char.

In stock: No Vendor stock: No Minimal order quantity: 1

Price (excl. VAT):

13,72 €

This price is valid until 24.12.25

EAN: 4016779599368

MPN: 2CDS271001R0035

Package: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	Miniature Circuit Breaker 3A, 10kA, 1 pole, B char.
Brand	ABB
Categories	Circuit breakers 3A
Country of origin	DE
Harmonized System Code	8536 2010 00
Rated current	3 A
Rated voltage	230 V
Release characteristic	B
Width in number of modular spacings	1
Number of poles (total)	1
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	10 kA

Packing details

Packing level 1

4016779599368

Other Technical data

Voltage type	AC/DC
Built-in depth	71 mm
Frequency	50-60 Hz
Rated insulation voltage Ui	440 V
Current limiting class	3
Over voltage category	3
Pollution degree	2
Degree of protection (IP)	IP20
Number of protected poles	1
Concurrently switching neutral conductor	No
Connectable conductor cross section solid-core	0.75-35 mm²
Ambient temperature during operating	-25-55 °C
Additional equipment possible	Yes
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	10 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	15 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	15 kA
Rated impulse withstand voltage Uimp	4 kV

Description

System pro M compact S200M miniature circuit breakers are current limiting. They have two different tripping mechanisms, the delayed thermal tripping mechanism for overload protection and the electromechanic tripping mechanism for short circuit protection. They are available in different characteristics (B,C,D,K,Z), configurations (1P,1P+N,2P,3P,3P+N,4P), breaking capacities (up to 10 kA at 230/400 V AC) and rated currents (up to 63A). All MCBs of the product range S200M comply with IEC/EN 60898-1 and IEC/EN 609 47-2, allowing the use for residential, commercial and industrial applications. Bottom-fitting auxiliary contact can be mounted on S200M to save 50% space.
