MIMIK 50 M 47 A60/W 30K DALI+EM3H ANT
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
Price by request
EAN: 8018367688412
MPN: 3104518
Package: 1
Estimate delivery time at our warehouse (approx.):
By request
Technical Information
| Item condition | New |
| Manufacture name | MIMIK 50 M 47 A60/W 30K DALI+EM3H ANT |
| Brand | Performance in Lighting |
| Categories |
Wall and ceiling luminaires
|
| Country of origin | IT |
| Harmonized System Code | 9405 1190 00 |
| Width | 500 mm |
| Colour housing | Anthracite |
| Colour rendering index CRI | 80-89 |
| Length | 500 mm |
| Height/depth | 91 mm |
| Lamp type | LED not exchangeable |
| Impact strength | IK06 |
| Nominal voltage | 220 V |
| Beam angle | Wide beam 41-80° |
| Colour temperature | 3000 K |
| Max. system power | 53 W |
Packing details
| Packing level 1 | 8018367688412, 8018367688412 |
Other Technical data
| Protection class | I |
| Lamp holder | Other |
| Conductor cross section | 2.5 mm² |
| Connection type | Screwed terminal |
| Voltage type | AC/DC |
| With movement sensor | No |
| Suitable for lamp power | 53 W |
| Type of grid | None |
| Type of control gear | LED operating device current-controlled |
| With light sensor | No |
| Suitable for suspended mounting | No |
| Number of poles | 7 |
| Housing material | Aluminium |
| Suitable for light line configuration | No |
| Suitable for emergency lighting | Yes |
| Light outlet | Direct |
| Light sharing | Asymmetric |
| Material cover | Glass transparent |
| With light source | Yes |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 | No |
| Covering of the luminaire with thermally insulating material possible | No |
| Suitable for number of lamps | 1 |
| Suitable for built-in mounting | No |
| With control gear | Yes |
| Suitable for workplace according to EN 12464-1 | No |
| Suitable for surface mounting | No |
| Colour of light | White |
| With air slots | No |
| Constant light output (CLO) | Yes |
| IFTTT support available | No |
| Type of wiring | Ending |
| Colour consistency (McAdam ellipse) | SDCM3 |
| Photobiological safety according to EN 62471 | RG1 |
| Rated ambient temperature according to IEC62722-2-1 | 0 °C |
| Dimming 0-10 V | No |
| Dimming 1-10 V | No |
| Dimming DALI | Yes |
| Dimming DMX | No |
| Dimming potentiometer (integrated) | No |
| Dimming manufacturer's proprietary system | No |
| Dimming mains voltage modulation | No |
| Dimming phase cut-off | No |
| Dimming phase cut-on | No |
| Dimming programmable | No |
| Dimming RF | No |
| Dimming Touch and Dim | No |
| Dimming Zigbee | No |
| Dimming with push-button | No |
| Light distributor | Refractor lens |
| Dimming DSI | No |
| Operation by Bluetooth | No |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| Max. number of luminaires per miniature circuit breaker C16 | 17 |
| Max. number of luminaires per miniature circuit breaker B16 | 10 |
| Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq) | 90 % |
| Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq) | 85.7 % |
| Lumen maintenance at median useful life of 75,000 h at 25 °C ambient (tq) | 78.9 % |
| Dimming DALI-2 | No |
| Colour temperature adjustable | No |
| Luminous flux adjustable | Continuously variable |
| Beam angle adjustable | No |
| Exchangeable control gear | Yes |
| Suitable for ceiling mounting | No |
| Surface protection housing | Lacquered |
| Power factor | 0.9 |
Downloads
Description
Serie LED wandarmaturen voor binnen en buiten bestaande uit: Behuizing van spuitgietaluminium gelakt met polyester poederlak. Het coatingproces is uitgevoerd met 13 verschillende passages met polyestherpoeder, zeer UV en weerbestendig. Siliconenpakking. Afscherming van vlak, gehard, extrahelder glas, aan de binnenkant bedrukt. Specificaties LED multichip 4000 K en 3000 K. Optische groep bestaande uit lenzen van technopolymeer met zeer hoge licht-doorgave. De versie EM/3P is ontworpen als 3 uur nood- en continu verlichting. Ni-Cd 3,6 V 4 Ah batterijen, autonomie 3 uur, oplaadtijd 24 uur. Autonomie 3 uur. Dimmen (DALI). De versies met CP optiek worden gekenmerkt door een asymmetrische lichtverdeling, geschikt voor de verlichting van voet- en fietspaden. De versies B met dubbele lichtuittreding gebruiken twee afzonderlijke ontstekingen voor lichtuittreding naar boven en naar beneden (DA).
