MF40 Butterfly Valve Actuator Schneider Electric 3-Wire Floating, 230Vac, 40Nm, Non-spring Return, IP54
Technical Information
| Item condition | New |
| Manufacture name | MF40-230F T54 00 |
| Brand | Schneider Electric |
| Categories |
Servo Motors
|
| Country of origin* | CH |
| * The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager. | |
| Model | Rotating |
| Control signal | Three-point |
| Degree of protection (IP) | IP54 |
| Regulation type on/off | Yes |
| Operating time | 150 s |
| Torque | 40 Nm |
| Stroke length | 0 mm |
| Supply voltage | 230 V AC |
Packing details
| Packing level 1 | 3606489660383 |
Other Technical data
| Width | 195 mm |
| Height | 145 mm |
| Depth | 78 mm |
| Housing material | Other |
| Ambient temperature | 0-50 °C |
| Suitable for manual operation | No |
| Potential free switch contact | No |
| Length of connection cable | 1 m |
| Explosion-proof | No |
| Regulation type modulating | No |
| Regulation type splitrange | No |
| Energy consumption in operation | 0 W |
| Energy consumption at rest | 0 W |
| Auxiliary contacts optional | No |
| Suitable for air accessory | No |
| Automatic travel recognition | No |
| With safety function | No |
| Deactivated when closed | No |
| Connection to stop valve | None |
| With mechanical setting indicator | Yes |
| Position reporting system | None |
| Suitable for valve | Yes |
| Max. electric power input | 9 VA |
| Max. angle of rotation | 0 ° |
| Allowable relative humidity | 0-95 % |
| Adjustable operating range | No |
| Return at zero supply voltage | No |
| Auxiliary contacts | Yes |
| End contacts | None |
| Adjusting force | 0 N |
| Self-adjusting travel length | No |
| Adjustable position feedback signal | No |
| With top flange direct mount according to ISO 5211 | No |
Description
Actuator for operating butterfly valves in HVAC and similar control systems. 3-wire control, used to achieve precise positioning with floating signals. Non-spring return model, works without mechanical failsafe; needs backup or manual override if power loss occurs.
Works on 230Vac input voltage. Rated torque: 40Nm (newton-meters), suitable for medium- to large-sized valves needing high force to operate. Enclosure is IP54-rated, so splash-proof but not fully waterproof—indoor use recommended unless in shielded outdoor cabinet.
Compact mounting footprint for easy integration into tight spaces, rotation range adjustable up to full open/close limits. No spring mechanism = less internal wear over time compared to some other designs that reset under load during power downtime.
