P1-32/I1/SVB Main switch, P1, 32 A, surface mounting, 3 pole, Emergency switching off function, With red rotary handle and yellow locking ring
In stock: No
Vendor stock: No
Minimal order quantity: 1
Price (excl. VAT):
35,43 €
EAN: 4015082339890
MPN: 233989
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | P1-32/I1/SVB Main switch, P1, 32 A, surface mounting, 3 pole, Emergency switching off function, With red rotary handle and yellow locking ring |
| Brand | EATON |
| Categories |
Switch Disconnectors
|
| Country of origin | GB |
| Harmonized System Code | 8536 5080 00 |
| Rated permanent current Iu | 32 A |
| Number of poles | 3 |
| Rated operating voltage | 690 V |
| Degree of protection (IP), front side | IP65 |
| Version as main switch | Yes |
| Version as safety switch | No |
| Version as maintenance-/service switch | Yes |
| Rated short-time withstand current lcw | 0.64 kA |
Packing details
| Packing level 1 | 4015082339890 |
Other Technical data
| Width | 80 |
| Height | 137 |
| Depth | 115 |
| Rated operation power at AC-3, 400 V | 13 kW |
| Number of auxiliary contacts as normally open contact | 0 |
| Number of auxiliary contacts as normally closed contact | 0 |
| Conditioned rated short-circuit current Iq | 80 kA |
| Number of auxiliary contacts as change-over contact | 0 |
| Number of switches | 1 |
| Interlockable | Yes |
| Motor drive integrated | No |
| Type of electrical connection of main circuit | Screw connection |
| Version as emergency stop installation | Yes |
| Type of control element | Door coupling rotary drive |
| Rated operation power at AC-23, 400 V | 15 kW |
| Colour control element | Red |
| Suitable for floor mounting | Yes |
| Suitable for front mounting 4-hole | No |
| Suitable for front mounting centre | No |
| Suitable for distribution board installation | No |
| Suitable for intermediate mounting | No |
| Max. rated operation voltage Ue AC | 690 V |
| Motor drive optional | No |
| Voltage release optional | No |
| Device construction | Complete device in housing |
| Rated permanent current at AC-21, 400 V | 32 A |
| Switching power at 400 V | 15 kW |
| Version as reversing switch | No |
| Rated permanent current at AC-23, 400 V | 32 A |
| Degree of protection (NEMA) | 12 |
| With pre-assembled cabling | No |
Description
Main switch, P1, Rated uninterrupted current (Iu): 32 A, Functions: Emergency switching off function, Interlockable, Fitted with: Red rotary handle and yellow locking ring, Mounting method: Surface mounting, Number of poles: Three-pole, Degree of Protection: NEMA 12
