basicDIM Wireless TECTON

TECTON module with integrated basicDIM Wireless (Bluetooth© CASAMBI) radio module Adapter made of sheet steel, pre-painted in polyester lacquer finish in white. Tool-free mechanical and electrical installation on the mounting rail via two side levers. Optimised for industrial, logistics, office and education applications. A BC TEC-GP module has a DALI bus supply that still supplies 40 mA minus the supply of the basicDIM Wireless module. This allows up to 20 luminaires to be controlled via DALI broadcast. No emergency lighting functionality. Individual addressing of TECTON luminaires not possible with basicDIM Wireless. Additional MSENS sensors (without basicDIM Wireless modules) can be used on the TECTON rail. This reduces the number of controllable luminaires. (1 sensor - 15 luminaires / 2 sensors - 11 luminaires / 3 sensors - 6 luminaires / 4 sensors (max) - 2 luminaires) Local control function: TECTON rail can be controlled by basicDIM Wireless (Bluetooth© CASAMBI) module with multi-sensor according to daylight and motion without additional central control unit. If several sensors are used, the lowest measured value of the light sensors is used, the movement messages are evaluated in total. As soon as no connected sensor reports movement, absence is detected. Only one basicDIM Wireless (Bluetooth© CASAMBI) may be operated per DALI circuit/rail. The TECTON TT-D1/D2 enables the DALI-side separation of the entire rail into individual sections. Each individual section can then in turn be equipped with a basicDIM Wireless (Bluetooth© CASAMBI) module. Permissible radio distance up to 15 m between individual basicDIM Wireless radio modules in other luminaires or TECTON inserts. Please refer to the installation instructions for further details. Temperature range from 0°C to +45°C; protection rating: IP20 Dimensions: 248 x 60 x 16 mm; weight: 0.5 kg
