Tridonic

LED modules

Tik užsakymas
Kaina (be PVM):
690,42 €
Ši kaina galioja iki kito kainoraščio arba tol, kol baigsis atsargos
EAN: 9006210739212
MPN: 28003449
Pakuotė: 1
Numatomas pristatymo laikas į mūsų sandėlį: 2-4 weeks

Technical Information

Prekės būklė Nauja
Gamintojo pavadinimas LED modules
Prekės ženklas Tridonic
Kategorijos LED moduliai
Plotis 14 mm
Ilgis 140 mm
Saugos laipsnis (IP) IP00
Lempos įtampa 39.7-48.5 V
Spalvos temperatūra 3000 K
Šviesos srautas 175-520 lm

Pakavimo informacija

Pakavimo lygis 1 9006210739212, 9006210739212

Kiti techniniai duomenys

Energijos taupymo klasė A++
Darbinė įtampa (diapazonas) 0 V
Šviesos spalva pagal EN 12464-1 Šiluma < 3300 K
Darbinė srovė 25-150 mA
Reikalinga išorinė pavara No

Aprašymas

Ideal for profile and linear luminaires made of extruded aluminium or sheet steel ¦ Simplified logistic through flexible cut option – every 140 mm cuttable ¦ 16 LEDs per 140 mm segment provide a very homogeneous light image, which remains uniform with a total length of 3 m when fed in from both sides ¦ Two wiring options available – for soldering only and with pre-mounted WAGO low-profile terminals for easy and shadow-free wiring every 280 mm ¦ Long lifetime up to 72,000 hours ¦ 5 years guarantee (conditions at www.tridonic.com) ¦ Colour temperatures 2,700, 3,000, 3,500 and 4,000 K ¦ Useful luminous flux 648 lm/m at Irated and tp = 25 °C ¦ Efficacy of the LED module 193 lm/W at Irated and tp = 25 °C ¦ High colour rendering index CRI > 80 and CRI > 90 ¦ Small colour tolerance (MacAdam 3) ¦ Small luminous flux tolerances ¦ The LLE FLEX CC is 14 mm wide, one tape is up to 25 m long and can be divided every 140 mm ¦ The 3M 93015LE adhesive tape ensures simple installation and optimum heat dissipation, it is long-term stable and weatherproof ¦ LED system solution with outstanding system efficacy up to 181 lm/W, consisting of linear LED flextape and a SELV LED driver
