emCON - Single battery controller image 1
emCON - Single battery controller image 2
emCON - Single battery controller thumbnail 1
emCON - Single battery controller thumbnail 2
Zumtobel

Single battery controller

Yra sandėlyje: Ne Pardavėjo atsargos: Ne Minimalus užsakymo kiekis: 1
Kaina (be PVM):
2 360,74 €
Ši kaina galioja iki 24.12.25
EAN: 9010299050250
MPN: 22171087
Pakuotė: 1
Numatomas pristatymo laikas į mūsų sandėlį (apytiksliai): Pagal užklausą

Technical Information

Prekės būklė Nauja
Gamintojo pavadinimas emCON - Single battery controller
Prekės ženklas Zumtobel
Kategorijos Šviestuvų priedai
Kilmės šalis CH
Suderintos sistemos kodas 8537 1098 00
Priedo tipas Kita

Pakavimo informacija

Pakavimo lygis 1 9010299050250, 9010299050250

Atsisiuntimai

DOC CE deklaracija (atitikties deklaracija CE) RoHS deklaracija Pardavimo brošiūra

Aprašymas

EmCON single battery controller for central control, visualisation and monitoring of single battery powered emergency luminaires from the ZUMTOBEL and THORN portfolio with the suffix E1D / E2D / E3D / E8D via the DALI interface; emergency luminaires are individually monitored by the controller; the result can be called up via the WEB interface without additional software; 64 luminaires can be supplied and monitored at each of three DALI output circuits; in the logbook function, the test results of the emergency luminaires required according to EN 62034 are stored in a non-volatile memory in the emCON controller and are not lost even if the device is completely switched off, enabling analysis over at least 3 years; with one unpowered LM bus output for integration of an optional LM-4 RUKS with 4 floating relay contacts and one optional ONLITE BRI for remote indication of overall status; 3 DALI lines with integrated power supplies for up to 192 DALI loads, 1 TCP/IP Ethernet RJ45 as well as screw terminals for 230V AC supply; emergency lighting controller in compact enclosure without rotating parts, for installing on 35mm DIN rails, permissible ambient temperature 0...50°C; dimensions: 160 x 91 x 62 mm, 9 HP of 17.5 mm each; weight: 0.6 kg
