basicDIM ILD G2 LC TEC-GP SR - TEC-GP with sensor and DALI control unit image 1
basicDIM ILD G2 LC TEC-GP SR - TEC-GP with sensor and DALI control unit image 2
basicDIM ILD G2 LC TEC-GP SR - TEC-GP with sensor and DALI control unit thumbnail 1
basicDIM ILD G2 LC TEC-GP SR - TEC-GP with sensor and DALI control unit thumbnail 2
Zumtobel

TEC-GP with sensor and DALI control unit

Yra sandėlyje: Ne Pardavėjo atsargos: Ne Minimalus užsakymo kiekis: 1
Kaina (be PVM):
453,49 €
Ši kaina galioja iki 24.12.25
EAN: 9010757197985
MPN: 22172571
Pakuotė: 1
Numatomas pristatymo laikas į mūsų sandėlį (apytiksliai): Pagal užklausą

Technical Information

Prekės būklė Nauja
Gamintojo pavadinimas basicDIM ILD G2 LC TEC-GP SR - TEC-GP with sensor and DALI control unit
Prekės ženklas Zumtobel
Kategorijos Šviestuvų priedai
Kilmės šalis AT
Suderintos sistemos kodas 9405 9900 00
Priedo tipas Judesio jutiklis

Pakavimo informacija

Pakavimo lygis 1 9010757197985, 9010757197985

Atsisiuntimai

Giluminė nuoroda REACH DOC CE deklaracija (atitikties deklaracija CE) RoHS deklaracija Pardavimo brošiūra

Aprašymas

The TECTON module with integrated basicDIM ILG G2 Wireless Sensor and DALI control unit is ideal for industry, logistics, offices and education. The sheet steel adapter, pre-painted in polyester lacquer finish in silver, enables tool-free installation on the mounting rail via two side levers. The basicDIM ILD G2 LC TEC-GP set consists of a PIR sensor (height 2-4 m) with integrated DALI control module and 2 DALI bus supplies with 126 mA free power for additional sensors and luminaires. It controls DALI luminaires via a broadcast signal without individual addressing. Up to 8 additional sensors (MSENS TEC-GP) can be added for motion detection. Light control is via the light sensor of the basicDIM ILD G2 module. 9 mA must be calculated per additional sensor and 2 mA per DALI luminaire, which means that, with a maximum of 8 additional sensors, 27 luminaires can still be controlled. In delivery state the system has activated motion detection and daylight-dependent light control with predefined time lags. The optional IR remote control (article no. 28003484) can be used to set all the main parameters. Further details can be found in the data sheet for the basicDIM ILD G2 sensor (article no. 28004639). The module must not be combined with other DALI control units or basicDIM ILD G2 modules. Temperature range 0°C to +50°C; dimensions: 248 x 60 x 16 mm; weight: 0.33kg
