Printed circuit board terminals, 3.81 mm, Number of poles: 7, 180°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape

Order only Minimal order quantity: 175

Price (excl. VAT):

1,85 €

This price is valid until 24.12.25

Subtotal: 323,75 € MOQ: 175

EAN: 4032248465385

MPN: 1875370000

Box: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	Printed circuit board terminals, 3.81 mm, Number of poles: 7, 180°, Solder pin length (l): 1.5 mm, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Tape
Brand	Weidmüller
Categories	PCB Connectors & Terminals
Country of origin*	DE
* The actual country of origin may differ depending on the delivery batch. To confirm the specific country of origin, please contact your account manager.
Harmonized System Code	8536 9010 00
Rated voltage	160 V
Number of levels	1
Rated surge voltage	2.5 kV
Degree of protection (IP), mounted	IP20
Angle PCB/conductor connection	90° (upwards vertical)
Rated current In	17.5 A
Number of electrical connections	7

Packing level 1

4032248465385

Height	15.5 mm
Colour housing	Black
Operating temperature	-50-120 °C
Type of fastening	Solder
Inflammability class of insulation material according to with UL94	V0
Over voltage category	II
Pollution degree	2
Connection type conductor	Push-in clamp connection
Connection type PCB	THR connection
Length pin	1.5 mm
Material connection surface	Tin
Modular spacing connections	3.81 mm
Type of banding	Other
Connectable conductor cross section solid-core	0.2-1.5 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.25-1.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.2-1.5 mm²
Material insulation body	Liquid crystal polymer
Type of PCB fastening	Other

PCB terminal block (print terminal, board terminal) for simple and safe data transmission directly to the PCB.
