Printed circuit board terminals, 3.50 mm, Number of poles: 2, 180°, tinned, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Box

In stock: No Vendor stock: No Minimal order quantity: 100

Price (excl. VAT):

5,43 €

This price is valid until 24.12.25

Subtotal: 543,00 € MOQ: 100

EAN: 4032248591848

MPN: 1934660000

Box: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	Printed circuit board terminals, 3.50 mm, Number of poles: 2, 180°, tinned, black, PUSH IN with actuator, Clamping range, max. : 1.5 mm², Box
Brand	Weidmüller
Categories	PCB Connectors & Terminals
Country of origin	DE
Harmonized System Code	8536 6990 00
Rated voltage	160 V
Number of levels	1
Rated surge voltage	2.5 kV
Degree of protection (IP), mounted	IP20
Angle PCB/conductor connection	90° (upwards vertical)
Rated current In	17.5 A
Number of electrical connections	2

Packing level 1

4032248591848

Height	28.6 mm
Colour housing	Black
Operating temperature	-50-120 °C
Type of fastening	Other
Inflammability class of insulation material according to with UL94	V0
Over voltage category	II
Pollution degree	2
Connection type conductor	Push-in clamp connection
Connection type PCB	Other
Material connection surface	Other
Modular spacing connections	3.5 mm
Type of banding	Other
Connectable conductor cross section solid-core	0.2-1.5 mm²
Connectable conductor cross section fine-strand with cable end sleeve	0.25-1.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.2-1.5 mm²
Material insulation body	Liquid crystal polymer
Type of PCB fastening	Other

PCB terminal block (print terminal, board terminal) for simple and safe data transmission directly to the PCB.
