Printed circuit board terminals, 3.50 mm, Number of poles: 12, 90°, Solder pin length (l): 3.2 mm, tinned, black, Clamping yoke connection, Clamping range, max. : 2.08 mm²

In stock: No Vendor stock: No Minimal order quantity: 50

Price (excl. VAT):

4,71 €

This price is valid until 24.12.25

Subtotal: 235,50 € MOQ: 50

EAN: 4050118208368

MPN: 1407760000

Box: 1

Estimate delivery time at our warehouse (approx.): 4-6 weeks

Technical Information

Item condition	New
Manufacture name	Printed circuit board terminals, 3.50 mm, Number of poles: 12, 90°, Solder pin length (l): 3.2 mm, tinned, black, Clamping yoke connection, Clamping range, max. : 2.08 mm²
Brand	Weidmüller
Categories	PCB Connectors & Terminals
Country of origin	SK
Harmonized System Code	8536 9010 00
Rated voltage	160 V
Number of levels	2
Rated surge voltage	2.5 kV
Degree of protection (IP), mounted	IP20
Angle PCB/conductor connection	0°/180° (horizontal)
Rated current In	11 A
Number of electrical connections	12

Packing level 1

4050118208368

Height	27.3 mm
Colour housing	Black
Operating temperature	-50-100 °C
Type of fastening	Solder
Inflammability class of insulation material according to with UL94	V2
Over voltage category	II
Pollution degree	2
Connection type conductor	Screw connection
Connection type PCB	Soldering connection
Length pin	3.2 mm
Material connection surface	Nickel
Modular spacing connections	3.5 mm
Connectable conductor cross section solid-core	0.5-1.5 mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.5-1.5 mm²
Material insulation body	Polyamide (PA)
Type of PCB fastening	Other

PCB terminal block (print terminal, board terminal) for simple and safe data transmission directly to the PCB.
