LK 80X28 T - Junction box for trunkings, configuration HB, colour super white/RAL9003, package - 10/100 pcs
Order Only
Price (excl. VAT):
0,97 €
per pcs
EAN: 8595057617308
MPN: LK 80X28 T_HB
Package: 1
Box: 100
Pallet: 3600
Estimate delivery time at our warehouse (approx.):
2-4 weeks
Technical Information
| Item condition | New |
| Manufacture name | LK 80X28 T - Junction box for trunkings, configuration HB, colour super white/RAL9003, package - 10/100 pcs |
| Brand | KOPOS |
| Categories |
Surface Mounted Junction Boxes
|
| Country of origin | CZ |
| Harmonized System Code | 3925 9080 00 |
| Halogen free | No |
| Equipped with | None |
| Rated insulation voltage Ui | 500 V |
| Sealable | No |
| Max. conductor cross section | 4 mm² |
| Weatherproof | No |
| Inlet from the rear | Yes |
Packing details
| Packing level 1 | 8595057617308 |
| Packing level 2 | 8595057617308 |
| Packing level 3 | 8595057617308 |
Other Technical data
| Mounting method | Wall-/ceiling mounting |
| Colour | White |
| Width | 80.5 mm |
| Depth | 28 mm |
| Shape | Square |
| Diameter | 0 mm |
| Length | 80.5 mm |
| Operating temperature | -5-60 °C |
| Material | Plastic |
| Number of inlets | 6 |
| Explosion-tested version | No |
| With screening | No |
| Tackable | Yes |
| Type of housing feed-through | Preembossing |
| Castable | No |
| With casting compound | No |
| Transparent cover | No |
| Mounting in the soil | No |
| Mounting under water | No |
Downloads
Description
LK 80X28 T - Box Trunking, configuration HB, colour SUPERwhite/RAL9003, package - 10/100 pcs - intended for instruments Tango with big assembly depth, intended for assembly without the need of using insulating washer
