Limit switch, four-pole, double-break, without indicator, roller lever D4AN2501M
Order only
Price (excl. VAT):
232,18 €
EAN: 4536853201401
MPN: D4A-2501N
Package: 1
Estimate delivery time at our warehouse (approx.):
4-6 weeks
Technical Information
| Item condition | New |
| Manufacture name | Limit switch, four-pole, double-break, without indicator, roller lever D4AN2501M |
| Brand | Omron |
| Categories |
Limit Switches
|
| Country of origin | NL |
| Harmonized System Code | 8536 5015 00 |
| Switching function | Quick-break switch |
| Rated operation current Ie at AC-15, 230 V | 3 A |
| Rated operation current Ie at DC-13, 230 V | 0.2 A |
| Suitable for safety functions | No |
| With status indication | No |
| Type of control element | Roller lever |
| Rated operation current Ie at DC-13, 125 V | 0.4 A |
| Rated operation current Ie at DC-13, 24 V | 3 A |
Packing details
| Packing level 1 | 4536853201401, 4536853201401 |
Other Technical data
| Housing material | Metal |
| Coating housing | Other |
| Type of interface for safety communication | None |
| Type of electric connection | Other |
| Explosion safety category for gas | None |
| Explosion safety category for dust | None |
| Construction type housing | Cuboid |
| Degree of protection (IP) | IP67 |
| Forced opening | No |
| Number of safety auxiliary contacts | 0 |
| Type of interface | None |
| Output electronic | No |
| Rated operation current Ie at AC-15, 125 V | 5 A |
| Width sensor | 29.4 mm |
| Height of sensor | 93.5 mm |
| Length of sensor | 62.5 mm |
| Switching function latching | No |
| Ambient temperature during operating | -40-100 °C |
| Number of contacts as normally closed contact | 2 |
| Number of contacts as normally open contact | 2 |
| Number of contacts as change-over contact | 0 |
| Alignment of the control element | Roller cam straight |
| Degree of protection (NEMA) | 4X |
Downloads
Description
Limit switch, four-pole, double-break, without indicator, roller lever
